Reinforced Density Floor Introduction of Slotted Line
Predicted output: (60 standard boards 60 per minute, 8 hours per day, production efficiency is expected to be 80%, equipment efficiency is 80%, 300 working days per year)
Annual output per shift is about 1 million square meters
(60 * 0.18 * 60 * 8 * 0.8 * 300 * 0.8 = 995, 328). The annual output of double shifts can be about 2 million square meters.
Maximum daily output (3 shifts) is about 10,000 square meters.
C—1:Longitudinal feeder
Function: Positioning and separating, after separating multiple boards, they are conveyed one after another to the next process.
C—2:Model: Longitudinal Double Side Milling MX115—400-G
Function: Fine and rapid contour machining of the longitudinal male and female edges of boards, using 5 stations and 10 shafts.
Features: High-strength and high-precision synchronous dual-track is adopted in the running track.
Basic Configuration
The high-strength track is adopted in the running chain track, and the linear precision is 0.01 mm.
Customized rolling conveying chain with intercept error of 0.005mm;
The upper pressure beam system is equipped with a digital display meter to manually adjust the thickness of the corresponding board.
Adjustable fixed guiding rule on the right side (female side);
Adjustable elastic side pressure roller on the left side (male side);
Passive elastic upper and side pressure rollers at the feeding inlet;
The upper and lower alloy material platform system is used to control the height difference, the lower alloy platform adopts adjustable fixed type, and the upper alloy platform adopts adjustable air pressure type. Guarantee the equal height of the plate surface, and the equal precision is 0.02 mm.
There are six processing stations (with scrapers) on one side, with 12 shafts in total. Each station is equipped with a suction inlet with a diameter of 110mm.
The cutter shaft is adjusted by T-type screw, and is equipped with a dial indicator for accurate adjustment. The precision can reach 0.01 mm.
The machine is equipped with high-light explosion-proof lamp, which strengthens the adjustment light atmosphere.
The machine is equipped with high-light explosion-proof lamp, which strengthens the adjustment light atmosphere.
Processing width | 115-400mm |
Processing thickness | 7-18mm |
Workbench height | 1210mm |
Speed of blade spindle | 6000-7000rpm |
Feeding speed | 5-80m/min |
Motor power of blade spindle | High Frequency Spindle (transducer control) |
First station | (1 left and 1 right) 8kw, combined stocking cutter, ± 90 degrees, up milling |
Second station | (1 left and 1 right) 8kw, truing cutter, ± 90 degrees, up milling |
Third station | (1 left and 1 right) 10kw, template, ± 90 degrees, up milling |
Fourth station | (1 left and 1 right) 5.5 kw, backboard rose reamer, ± 90 degrees, up milling |
Fifth station | (1 left and 1 right) 5.5kw, locking cutter, ± 90 degrees, up milling |
Feeding electrical machinery | 5.5kw (frequency conversion control) |
Blade tool specification | Diameter is 250 (equipped with hydraulic shrink disk), Aperture diameter is 40 |
Diameter and quantity of suction outlet | 110mm*10*2 (inside and outside) Overall dimension(mm) |
Length x width x height | 5595x2000x2150 |
Weight | About 9,000 kg |
C—3: Intermediate conveyor
Function: After processing of longitudinal double-sided milling, the board is conveyed to the next process.
C—4:Transverse double-end milling MX600-1300-G
Function: Accurate and rapid contour machining of the transverse male and female edges of the board, using 5 processing stations and 10 shafts with scrapers.
Basic Configuration
◈ High-precision and high-strength positioning chain, the linear precision is 0.01 mm; length adjustment can be operated by screen touch, high-precision double screw positioning, frequency conversion control;
◈ Bearing rolling conveying chain, the intercept error is 0.005mm;
◈ The passive upper pressure beam system is equipped with digital display meter to manually adjust the corresponding floor thickness.
◈ Passive multiple-roller loader is equipped between the two tracks, which greatly reduces the defective percentage caused by bending work of boards.
◈ There is a stock bin for entering of boards and photoelectric control in the front. The maximum continuation height of the stock bin is 200 mm. When the board goes out of the stock bin, the female side on the right is an adjustable fixed guiding rule, and the male side on the left is an adjustable elastic baffle to ensure the left and right positions of the board. A special secondary feeding system is configured to precisely synchronize the positioning of feeding.
◈ The upper and lower alloy material platform system at the tool nose is used to control the height difference. The lower alloy platform adopts adjustable fixed type, and the upper alloy platform adopts adjustable vapour-pressure type, to ensure the equal height of the board surface, and the equal precision is 0.02 mm.
◈ There are 5 processing stations on one side, with 10 shafts in total. Each station is equipped with a suction inlet with a diameter of 110mm.
◈ The cutter shaft is adjusted by T-type screw, and is equipped with a dial indicator for fine adjustment, with an precision of 0.01 mm.
◈ The machine is equipped with a acoustic enclosure with sound-absorbing cotton.
◈ The machine is equipped with high-light explosion-proof lamp, which strengthens the adjustment light atmosphere.
1. Processing length | 600-1300mm |
2. Processing thickness | 6-18mm |
3. Workbench height | 1020mm |
4. Speed of cutter shaft | 6000-7000rpm |
5. Feeding speed | 5-80m/min |
6. Motor power of cutter shaft | High Frequency Spindle (Frequency Conversion Control) |
First station | (1 left and 1 right) 5.5kw, combined stocking cutter, ± 90 degrees, up milling |
Second station | (1 left and 1 right) 5.5kw, truing cutter, ± 90 degrees, up milling |
Third station | (1 left and 1 right) 5.5kw, template, ± 90 degrees, up milling |
Fourth station | (1 left and 1 right) 5.5 kw, backboard rose reamer, ± 90 degrees, up milling |
Fifth station | (1 left and 1 right) 5.5kw, locking cutter, ± 90 degrees, up milling |
7. Feeding electrical machinery | 4kw (frequency conversion control) |
8. Specification of blade tools | Diameter is 250 or bigger (using hydraulic shrink disk), aperture is 40 |
9. Diameter and quantity of suction port | 115mm*10*2 (inside and outside) |
10. Overall size (mm), length x width x height | 5000x3100x1900 |
11. Weight | About 9,000 kg |
C—5: Windmill turnover machine
Function: The belt conveyor board is turned to the right side by photoelectric induction and windmill rotation, and enters the next process.
Length: 2000mm
Width: 640
Speed (adjustable): 5-80 m/min, frequency conversion windmill rotation.
